X Series
-
Vertical turret milling machine are widely used for processing flat face, slope surface face, keyway, key groove, slot, drilling, reaming, boring. The milling head can turn 90° each side, 45° with front and rear. Ram can turn 360° on flat. Spindle speed range is bigger and higher speed. The spindle sleeve feeding can be set. It is equipped with over load protection device. Spindle sleeve and guide way is high frequency quenching. Our lathe is good looking and practical.
|
Specifications |
X6325 |
X6330 |
| Table size (mm) | 254×1270254×1370 | 305×1370305×1500 |
| Long travel (mm) | 850/950 | 870/1000 |
| Cross travel (mm) | 420 | 380 |
| Verlical travel (mm) | 420 | 430 |
| T-slot no and size | 3×16 | 3×16 |
| Ram travel (mm) | 470 | 500 |
| Distance from spindle to toble surface(mm) | 0~405 | 0~350 |
| Spindle taper | R8(standard)IS030/ISO40(optional) | ISO40(standard) |
| Spindle travel (mm) | 127 | 127 |
| Spindle speed (rpm) | 65~4500 | 65~4500 |
| Auto. quill feed (mm/rev) | 0.04/0.08/0.15 | 0.04/0.08/0.15 |
| Spindle motor (kW) | 2.25 | 3.75 |
| Head swivel | 90° | 90° |
| Head tilting | 45° | 45° |
| Dimension of package (mm) | 1516×1550×2080 | 1566×1650×2080 |
| Weight (Kg) | 1550 | 1700 |
